Hinen 10kWh Battery
The Hinen 10kWh (B5000 x2) Battery is a scalable energy storage solution that combines two Hinen B5000 units, providing enhanced capacity for residential and commercial applications.
Key Features of Hinen 10kWh Battery
Increased Capacity: By combining two 5kWh B5000 batteries, the total energy storage capacity is 10kWh, making it suitable for larger energy needs.
Safety Features: It includes a comprehensive 5-layer battery protection system:
Full coverage temperature detection
Intelligent Battery Management System (BMS) with over-temperature, over-current, and over-voltage protection
Built-in physical short-circuit protection
Internal aerosol fire extinguisher
Decompression valve
IP65 Rating: This ensures the battery is protected against dust and water, making it suitable for various environmental conditions.
Scalability: The system can be expanded from 10kWh to a maximum of 30kWh by adding additional B5000 units in parallel.
Remote Monitoring: Users can track energy usage and receive updates via the Hinen app.
Technical Specifications
Model Hinen 10kWh (B5000 x2)
Total Energy Capacity 10kWh
Nominal Voltage 48V DC
Voltage Range 44.8V – 57.6V DC
Battery Type Lithium Iron Phosphate (LiFePO4)
Cycle Life > 5,000 cycles at 80% DoD
Charging Voltage 55.2V – 57.6V DC
Max Charging Current 100A
Max Discharging Current 100A
Operating Temperature Range -20°C to +55°C
Dimensions (L x W x H) Varies with configuration
Weight Approximately 90 kg (combined)
Warranty 10 Years
Applications
The Hinen 10kWh battery is ideal for:
Residential energy storage systems that require more power.
Off-grid solar power installations needing higher capacity.
Small to medium-sized commercial applications.
This battery system provides a reliable and efficient way to store energy, supporting users in reducing electricity costs while ensuring a continuous power supply. Its scalability allows for future expansion as energy needs grow.
